Ruggedized Slip Rings

SVTS D Series

The SVTS D series electric rotary joints, with their rugged design characterized by all stainless steel external components, make them a very robust product for applications in harsh environments.
This family of rotary joints is available in two series that differ from the electrical configuration, the former having a maximum current of 5A per circuit. At the same time, the latter can reach up to 15A continuous.

Technical Specifications

Up to 20A
Up to 96 circuits
Stainless steel construction
IP65

Attributes

Customizable
High data-rate
IP65

Download

Servotecnica-Slip Rings

SVTS D Series

Attributes

Customizable
High data-rate
IP65

Technical Specifications

Up to 20A
Up to 96 circuits
Stainless steel construction
IP65

Download

Servotecnica-Slip Rings

SVTS D Series

Model	5A circuits	L	PG type
SVTS D 01-U-A-00/06	6	63	PG7
SVTS D 01-U-A-00/12	12	77	PG9
SVTS D 01-U-A-00/18	18	91	PG11
SVTS D 01-U-A-00/24	24	105	PG16
SVTS D 01-U-A-00/30	30	119	-
SVTS D 01-U-A-00/36	36	133	-
SVTS D 01-U-A-00/42	42	147	-
SVTS D 01-U-A-00/48	48	161	-

Model	Total circuits	15A circuits	2A circuits	L
SVTS D 02-U-A-06/00	6	6	-	59
SVTS D 02-U-A-00/12	12	-	12	59
SVTS D 02-U-A-12/00	12	12	-	83
SVTS D 02-U-A-06/12	18	6	12	83
SVTS D 02-U-A-00/24	24	-	24	83
SVTS D 02-U-A-18/00	18	18	-	106
SVTS D 02-U-A-12/12	24	12	12	106
SVTS D 02-U-A-06/24	30	6	24	106
SVTS D 02-U-A-00/36	36	-	36	106
SVTS D 02-U-A-24/00	24	24	-	130
SVTS D 02-U-A-18/12	30	18	12	130
SVTS D 02-U-A-12/24	36	12	24	130
SVTS D 02-U-A-06/36	42	6	36	130
SVTS D 02-U-A-00/48	48	-	48	130
SVTS D 02-U-A-30/00	30	30	-	154
SVTS D 02-U-A-24/12	36	24	12	154
SVTS D 02-U-A-18/24	42	18	24	154
SVTS D 02-U-A-12/36	48	12	36	154
SVTS D 02-U-A-06/48	54	6	48	154
SVTS D 02-U-A-00/60	60	-	60	154
SVTS D 02-U-A-36/00	36	36	-	178
SVTS D 02-U-A-30/12	42	30	12	178
SVTS D 02-U-A-24/24	48	24	24	178
SVTS D 02-U-A-18/36	54	18	36	178
SVTS D 02-U-A-12/48	60	12	48	178
SVTS D 02-U-A-06/60	66	6	60	178
SVTS D 02-U-A-00/72	72	-	72	178
SVTS D 02-U-A-42/00	42	42	-	202
SVTS D 02-U-A-36/12	48	36	12	202
SVTS D 02-U-A-30/24	54	30	24	202
SVTS D 02-U-A-24/36	60	24	36	202
SVTS D 02-U-A-18/48	66	18	48	202
SVTS D 02-U-A-12/60	72	12	60	202
SVTS D 02-U-A-06/72	78	6	72	202
SVTS D 02-U-A-00/84	84	-	84	202
SVTS D 02-U-A-48/00	48	48	-	237
SVTS D 02-U-A-42/12	54	42	12	237
SVTS D 02-U-A-36/24	60	36	24	237
SVTS D 02-U-A-30/36	66	30	36	237
SVTS D 02-U-A-24/48	72	24	48	237
SVTS D 02-U-A-18/60	78	18	60	237
SVTS D 02-U-A-12/72	84	12	72	237
SVTS D 02-U-A-06/84	90	6	84	237
SVTS D 02-U-A-00/96	96	-	96	237
